Pipe Support Securement
Pipe on a roof has to do three things at once: hold a grade, expand and contract with the seasons, and stay off the membrane. Blocks and sleepers manage the third one badly and the first two not at all. Pipe Support Securement carries the run on adjustable stands set on a 3000 Series U-Anchor® base: an elevated stand for a fixed run, and a roller stand where the pipe has to move. Items placed above the roof are commonly considered overburden and excluded from the roof warranty. The Compression-Free™ U-Anchor® is considered a component of the roof and included in the warranty.
The assembly from every angle
PSS 0310 — Strut Assembly: a 12" strut on stand-off posts, carrying a pipe run 5" to 18" clear of the roof on a 3000 Series U-Anchor®.
Drag to turn it
PSS 0320 — Roller Assembly: the pipe rides between two rollers, free to expand and contract along the run, on a 3000 Series U-Anchor®.
Drag to turn it
PSS 0300 — 12" Base: a 12" strut bolted straight onto a 3000 Series U-Anchor®, holding the pipe 2" off the roof.
Drag to turn it
How it works
It starts with a U-Anchor®, a component of the roof, sealed watertight at the point of attachment. Everything else connects your equipment to that one point.
The part that carries the load. A galvanized steel plate with rolled edges that protect the membrane sits under a cover membrane matched to the roofing brand, type, and color, leaving a stainless stud at the surface for everything else to bolt to. Which one you use is decided by the membrane on the building, not by the equipment.
12" strut, Strut cap — fitted to the equipment itself rather than to the roof.
The part that carries the load. A galvanized steel plate with rolled edges that protect the membrane sits under a cover membrane matched to the roofing brand, type, and color, leaving a stainless stud at the surface for everything else to bolt to. Which one you use is decided by the membrane on the building, not by the equipment.
6" strut, Strut cap — fitted to the equipment itself rather than to the roof.
The part that carries the load. A galvanized steel plate with rolled edges that protect the membrane sits under a cover membrane matched to the roofing brand, type, and color, leaving a stainless stud at the surface for everything else to bolt to. Which one you use is decided by the membrane on the building, not by the equipment.
Stand-off post, All-thread, Compatible bolt and washer kit, 12" strut, Strut cap — fitted to the equipment itself rather than to the roof.
The part that carries the load. A galvanized steel plate with rolled edges that protect the membrane sits under a cover membrane matched to the roofing brand, type, and color, leaving a stainless stud at the surface for everything else to bolt to. Which one you use is decided by the membrane on the building, not by the equipment.
Stand-off post, All-thread, Compatible bolt and washer kit, Pipe roller, Rod cap — fitted to the equipment itself rather than to the roof.
The part that carries the load. A galvanized steel plate with rolled edges that protect the membrane sits under a cover membrane matched to the roofing brand, type, and color, leaving a stainless stud at the surface for everything else to bolt to. Which one you use is decided by the membrane on the building, not by the equipment.
Strut frame, Pipe rollers with securement — fitted to the equipment itself rather than to the roof.
